Ultimate pressure of 100 Pa [abs] or lower.
(※According to JIS Z8126-1.)

Low-lying design for easy fitting into other equipment.

Clean exhaust air that doesn't dirty your work environment with oil.
32,000-hour overhaul cycle.
(Requires maintenance every 8,000 hours. Refer to the instruction manual for details.)

Vacuum Forming
Vacuum Packaging
Deaeration
Leak Testing
Vacuum Cleaning and Drying
Food Cooling
Impregnation
Gas Displacement
Medical Aspiration

1. Models for 50 Hz and 60 Hz regions are different.


2. The flow rate is the theoretical value based on the designed pumping capacity. Please confirm the actual flow rate on the Discharge Air Curve Chart.


3. The attainable value is the actual value measured at 200 V, however this is not a guaranteed value.


4. NPSC1/2 has a thread pitch very similar to that of Rc1/2, and therefore R1/2 threaded connections can be used.


5. The allowable intermittent power supply voltage fluctuation range is +10% of the specified voltage and the allowable sustained supply voltage fluctuation range is ±5% of the specified voltage


6. Please consult with ORION if the product is to be operated at an elevation above 1000 m.

Operating Conditions:20℃, Static condition flow rate.
Typical value for standard built-in motor and not a guaranteed value.
Graph shows absolute pressure.
